Miller Spectrum® 375 Plasma Cutter w/XT30C Torch 907532
Miller Spectrum® 375 plasma cutter now features the new XT30C plasma torch. Solid state design and Miller's reliable technology pack a ton of performance into the portable, 49 pound plasma cutter. This versatile power source adapts to the shop or work site by operating on either 115 or 230 volt AC power. This machine can cut 1/2 inch mild steel with a stand off, and can drag cut 3/8 inch mild steel. With new features such as the Pilot Arc Controller, Heavy-duty work clamp, and Ergonomic XT30C plasma torch, the Spectrum® 375 CutMate™ is the clear winner in its class.
The new Miller XT30C plasma torch has a comfortable, ergonomic design and fetures an extremely flexible cable.
Applications Processes
Industrial Applications
Auto Body
Maintenance
Fabrication
Light Construction
HVAC Ductwork
Prototyping
Air Plasma Cutting
Features:
Pilot Arc Controller increases cutting capabilities and speeds, and improves tip life.
Capable of Drag Cutting quality cut (approx. 7 IPM) at 3/8" mild steel. Stand Off quality cut (approx. 7 IPM) at 1/2" mild steel.
Power Factor Correction expands operator's work area via extension cords with less nuisance tripping than previous model. Allows the Spectrum 375 CutMate to use up to 50 ft of 12 AWG extension cord on 115V, 20 Amp service and to draw 20% less current when cutting and than the previous model.
Increased Line Voltage Compensation regulates input power to a fixed value as line voltage droops or spikes by +/- 15% for steadier cuts and cleaner ending cuts.
Advanced Flashing LED indicators for pressure, power, cup and temperature allow faster troubleshooting eliminating unnecessary downtime.
Ergonomic design of XT30C torch with increased comfort, safety trigger, and improved flexible cable.
Dual input voltage located in back of units allows either 115 or 230 VAC input power and provides patented protection in case of incorrect switch position. Unit provides full cutting capacity when powered by most engine-driven welders with 240 VAC auxiliary receptacles.
Compatible with engine-driven welders capable of cutting 3/8 to 1/2 in mild steel when powered by a Miller engine-driven welder with 6000 watts, 240 V receptacle.
Starts without high-frequency so it will not interfere with controls or computers.
Postflow cooling circuit extends the life of the consumables and torch by cooling them with postflow air after the trigger is released.
Consumables storage compartment provides convenient access to consumables and parts.
Gas/air filter/regulator inside the power source provides added protection during transportation. Standard air connection on back panel for easy gas or air hookup.
LVC Line Voltage Compensation - Keeps output of the power source constant regardless of fluctuation in input power +/- 10%.
Specs
Comes Complete With:
Spectrum® 375 Plasma Cutter
XT30C hand-held torch with 20 ft cable.
20 ft HEAVY-DUTY work cable with clamp
Extra consumables (3 electrodes, 3 tips, and 1 air fitting)
10 ft power cord with 115 VAC, 20 A plug
Easy-to-connect, built-in gas/air filter and regulator with extra protection.
Free standard ground shipping within contiguous U.S.
|
|
|
