Miller Bobcat® 3 Phase Welder 907505
The Miller Bobcat® 3 Phase welder generator is designed for farm and ranch owners in need of both single and three-phase power to run 480V three-phase pivot irrigation systems or to provide backup power for home, farm and ranch.
The redesigned Miller Bobcat® 3 Phase is quieter to operate, smaller and lighter and easier to maintain.
Processes
Stick Welding (SMAW)
Flux Cored Welding (FCAW) *
MIG Welding (GMAW) *
DC TIG Welding (DC GTAW)
Non-Critical AC TIG Welding (GTAW)
Air Carbon Arc (CAC-A) Cutting and Gouging (3/16 in carbons)
Air Plasma Cutting and Gouging (PAC) with Optional Spectrum Models
* with voltage-sensing feeder
Applications Generator Power For:
Farm or Home Backup
Pivot Irrigation Systems
Pumps
Conveyors
Welding Applications:
Farm Equipment Repair
Maintenance
Fabrication
Features: Features
IMPROVED! Quieter and Better Sound - Significant improvements in sound level and quality offer better jobsite communication, which provides a safer, more efficient working environment for you and your crew. New Bobcat 3 Phase welder/generators have rotated the engine toward the front to create more efficient airflow, resulting in significantly quieter operation. Now you can start your job earlier in the day and end it later, as well as work around hospitals, businesses, and residential areas.
IMPROVED! Smaller and Lighter Design - New Bobcat 3 Phase welder/generators take up less space on trucks and trailers - leaving more room on your truck for other equipment and tools. Plus, they're easier to move safely around jobsites - even with weld cables and running gear attached.
IMPROVED! Easier Maintenance - With its intuitive design, the daily maintenance of the new Bobcat 3 Phase welder/ generators is faster and easier. With front panel maintenance displays, you know when your equipment needs to be serviced. And servicing is simple because of: Oil checks that can be performed from the top by the front panel
Toolless panels that allow for quick access
Single-side fuel fill and oil drain/filter
Long Runtimes - Large 12-gallon fuel capacity means many hours of run time before refueling.
Versatile AC and DC Weld Output - Provides quality welds on all types of metals. DC is smooth and easy to run while AC Stick is used when arc blow occurs.
Accu-Rated™, Not Inflated Generator Power - Miller's Accu-Rated™ 11,000 watts of usable peak power is delivered for a minimum of 30 seconds. Accu-Rated means peak power is usable for maximum generator loads such as plasma cutting, Millermatic® MIG welders and motor starting. Accu-Rated peak power beats the competition's very short duration peak or surge power. Use your peak power, it's more than a number.
Smooth Power - Not Spike Power - Revolutionary ten-degree skewed-rotor design optimizes generator performance for smoother power, not spiked power found with other brands. Better power, better performance.
PLUS get a FREE Miller® Infinity™ auto-darkening welding helmet with the purchase of this Miller® Bobcat® 3 Phase welder. While supplies last. (No substitutions allowed.)
Digital Infinity™ Features
ClearLight™ lens technology optimizes contrast and clarity in welding and light states - reducing eye strain and operator fatigue
13.4 sq. in. viewing area provides the largest view in the industry
InfoTrack® features arc time tracking, time and timer functions, and a multi-language help menu.
Four arc sensors for superior lens response
Four Operating Modes - Weld, Cut, Grind, and X-Mode
Digital controls allow user to easily adjust mode and settings
Auto-On/Off power control triggers lens at the strike of an arc
Redesigned headgear with oversized comfort cushion provides extensive adjustability, settings, and enhanced support.
Digital Infinity™ Specs
Comes complete with
5 outside cover lenses
2 inside cover lenses
Mag lens holder
Helmet bag
Three year lens warranty
