Description
Lincoln® POWER MIG® 180 Dula MIG Welder K3018-2
The Lincoln® POWER MIG® 180 Dual is a 180 amp portable MIG welder that operates on 120 volt or 208/230 volt input power. Multi-voltage technology allows the 180 Dual to plug into a standard household 120 volt outlet or industrial 230 volt outlet. The 180 Dual features Diamond Core Technology™ which supplies a smooth, stable arc in all welding positions, while reducing spatter. The cast aluminum industrial wire drive system delivers smooth consistent feeding of your solid MIG welding wire or flux-cored wire. The wire drive turns both drive rolls for reliable welding wire feeding without "bird nesting."
The POWER MIG 180 Dual comes complete with a 10 foot Magnum® PRO MIG gun with long-life contact tips and Magnum® PRO parts. It has built in spool gun circuitry, for quality aluminum MIG welds using the OPTIONAL Magnum® 100SG spool gun. The 180 Dual weighs 68 lbs. and produces up to 180 amps of MIG welding output. It runs on 120V or 208V/230V single-phase input power and comes complete with two input power cables plus a three-year warranty.
Processes
MIG (GMAW)
Flux-Cored (FCAW)
Applications
Metal Fabrication
Maintenance and Repair
Auto body/Farm
Light Industrial
Features
Dual Input Voltage
120 volt or 208/230 volt, single-phase
Select 120 volt input power for home and generator driven environments or choose 208/230 volt input power for shop applications on thicker materials.
No tools required – Just attach the correct input power cord and twist the locking nut.
Input cable bag included – When not in use, stow your input power cables and other accessories in the standard, detachable canvas bag.
Diamond Core Technology™
Delivers a forgiving arc, excellent out-of-position arc stability, low spatter and a wide voltage
sweet spot at a given wire feed speed for steel, stainless steel or aluminum.
Industrial Cast Aluminum Wire Drive
Dual gear-driven drive rolls deliver positive traction.
Patented split wire guides ensure optimal wire alignment and a brass-to-brass gun connection aids critical conductivity.
A large industrial closed design drive motor improves torque and enhances trouble-free performance.
No Hassle Tool-less Design
No tools are required for input power changes, wire spool mounting, wire drive service and polarity changes.
10 ft. Magnum® PRO MIG Gun
Includes extended life Magnum® PRO contact tips and MIG consumables last longer than standard MIG consumables.
Add a spool gun
The POWER MIG® 180C is spool gun ready for the OPTIONAL Magnum® PRO 100 SG spool gun.
Toughest PC Board Protection in the Industry
"Potted" to seal sensitive components from the environment
"Trayed" in a tough plastic tray to add rigidity and shock resistance.
Comes complete with
POWER MIG® 180 Dual MIG Welder 120/208/230 volt, single-phase
120V and 230V Input Cables
Input Cable Bag
Magnum® PRO 100L 10 ft. MIG Gun
035 in. (0.9 mm) and .025 - .030 in. (0.6 - 0.7 mm) Drive Rolls
.030 - .045 in. (0.7 - 1.1 mm) Knurled Drive Roll
.025 - .035 in. (0.6 - 0.9 mm) and .035 - .045 in. (0.9 - 1.1 mm) Wire Guides
Gas and Gasless Nozzles
Cable Liner
.025 in. (0.6 mm) and .035 in. (0.9 mm) Contact Tips Work Cable and Clamp
Adjustable Gas Regulator and Hose
Spindle Adapter
Sample Spool of .025 in. (0.6 mm) SuperArc® L-56 Mild Steel MIG Wire
Sample Spool of .035 in. (0.9 mm) Innershield® NR-211-MP Flux-Cored Wire
Learn-To-Use DVD
FREE Lincoln® Viking™ 1740 Black auto-darkening welding helmet.
Get a FREE Viking™ 1740 series Black auto-darkening welding helmet with purchase of this POWER MIG® 180 Dual MIG welder. Expires 3/31/23. (No substitutions allowed.)
The Lincoln® Viking™ 1740 Black auto darkening welding helmet features a perfect 1/1/1/1 optical clarity rating. The 1740 comes with Lincoln's exclusive 4C® lens technology. Proprietary 4C liquid crystal display passes more true color through the lens in both light and dark states to create the clearest view of your work piece. Lens distortion and blurriness are completely eliminated, shade is consistent through every square inch of the lens and the welding arc looks crisp and clear at any angle.
The Lincoln Viking 1740 auto darkening welding hood comes complete with variable shade 9-13 lens with delay and sensitivity controls. It is rated for DC TIG welding down to 5 amps and has a two year lens warranty.
Viking™ 1740 Features
4C™ lens technology Optimizes contrast
and clarity in welding and light states - reducing eye strain and operator fatigue
Improved Padding for Headgear - New material and foam for a more comfortable fitting sweatband and backpad
Grind Mode Indicator- Green flashing LED inside the helmet tells you when the helmet is in grind mode
Variable shade 9-13 lens - Has internal controls with delay and sensitivity functions.
Perfect 1/1/1/1 Optical Clarity -
This rating is determined by measuring blurriness, distortion, shade consistency and angle uniformity of the auto-darkening welding lens
Two arc sensors
DC TIG rated to 5 amps - Good performance on low amperage DC TIG welding applications.
Auto On/Off
Comes complete with
5 outside cover lenses
2 inside cover lenses
Mag lens holder
Sticker sheet
Two year lens warranty
PLUS get a $750 VISA® gift card from Lincoln® with the purchase of this POWER MIG® 180 Dual MIG welder. Rebate form must be submitted online HERE no later than 30 days after purchase. While supplies last.
This item ships Free via standard ground shipping within contiguous U.S.
