Miller® Dynasty® 280 DX Multiprocess Wireless Complete Package with ArcReach® SuitCase® 12VS Wire Feeder 951878
The Miller® Dynasty® 280 DX Multiprocess Wireless Complete is a fully integrated 280 amp water-cooled AC/DC TIG and air-cooled MIG welding package with Small Runner™ cart. It comes complete with all the equpment necessary for full feature AC/DC TIG welding and includes an ArcRech® Suitcase® 12VS wire feeder for MIG welding. The Dynasty 280 DX multiprocess welder comes assembled with Coolmate™ 1.3 water cooler and Small Runner™ cart. It is capable of stick and advanced TIG welding and has CV circuitry for MIG welding. The 280 DX multiprocess is the only welder you'll need on the jobsite to perform MIG, Stick, AC/DC TIG welding and air carbon arc gouging.
The Dynasty 280 DX multiprocess has built in TIG pulse and advanced AC wave forms and provides up to 280 amps of welding output. At just 55 pounds, the Dynasty 280 DX multiprocess can weld materials up to 3/8 inch thick, yet weighs hundreds of pounds less than comparable welders in the same welding output class. When using a water-cooled TIG torch, the 280 DX multiprocess utilizes Cooler-On-Demand™ technology to save energy and prolong the life of your TIG torch and Miller Coolmate™ 1.3 cooler. The ArcReach Suitcase 12 voltage sensing wire feeder handles solid MIG welding wire up to .052 diameter and up to 5/64 flux-cored wire.
IP23 rating — This equipment is designed for outdoor use. It may be stored, but is not intended to be used outside during precipitation unless sheltered.Processes
AC/DC TIG (GTAW)
Pulsed TIG (GTAW-P)
Air carbon arc (CAC-A)
MIG (GMAW) - with INCLUDED ArcReach 12 voltage sensing feeder.
Pipe and tube fabrication
Maintenance and repair
Built-in CV circuitry for MIG welding when paired with INCLUDED 12VS voltage sensing feeder.
The DX model offers full AC features, including advanced waveforms and wide ranges of balance and frequency.
Built-in pulser reduces heat input; adds arc stability.Upgradeable and expandable.
Front panel memory card data
port provides the ability to easily
upgrade software and expand
Pro-Set™ feature (professional
eliminates the guesswork
when setting weld parameters.
Use Pro-Set when you want
the speed, convenience and
confidence of pre-set controls.
Simply select the feature and
adjust until Pro-Set appears on
the display. The Pro-Set feature is
available for Balance, Frequency,
Pulse, and DIG parameters.
This programmable feature will
power down the machine if it sits
idle for a specific time.
Auto-Line™ provides state-of-the-art flexibility by automatically connecting to 208-575 VAC, single- or three- phase power without removing the covers to relink the power source. No longer is there a concern if you have the correct machine for the shop or the job site.
Cooler Power Supply (CPS). An
integrated 120-volt dedicated-use
receptacle to power the Coolmate™ 1.3.
The power switch on the Dynasty also
activates the receptacle to help prevent
Lift-Arc™ starting provides x-ray clean
welds in AC or DC arc starting without
the use of high frequency.
starter for non-contact arc initiation.
Provides more consistent arc starts and
greater reliability compared to traditional
HF arc starters. Easy to
set and increases
Digital meters can be calibrated to a
standard device for certification.
Wind Tunnel Technology™ protects internal electrical
components from airborne contaminates, extending the
Fan-On-Demand™ power source cooling system operates
only when needed, reducing noise, energy use and the
amount of contaminates pulled though the machine.
Cooler-On-Demand™ feature operates
only when needed,
energy use, and airborne contaminants pulled
through the cooler.
Thermal Overload Protection -
Internal components are protected from damage by thermal overload protection which automatically shuts down the unit if duty cycle is exceeded or air flow and cooling are restricted.
Comes standard - with improved Miller® wireless remote foot control and receiver. Receiver plugs directly into the 14-pin receptacle of Miller machine.
90-foot (27.4 m) operating range.
IP23 rating - This equipment is designed for outdoor use. It may be stored, but is not intended to be used outside during precipitation unless sheltered.
AC TIG Features
AC Pulsed TIG standard
0.1 to 500 PPS
AC Balance (50-99%) controls the amount of oxide cleaning (amperage time in EN) which is essential for high quality welds on aluminum.
AC frequency (20-400 hz)controls the width of the arc cone and the force of the arc.
Advanced AC Waveforms
DC TIG Features
DC Pulsed TIG standard
0.1 to 500 PPS
Exceptionally smooth and precise arc for welding exotic materials.
CV output of the power source gives this unit
MIG process capabilities when paired with the included ArcReach® Suitcase® 12VS (or other voltage sensing
feeder). The feeder is powered off the
arc voltage of the power source and can run
both solid and flux-cored wires
Stick Features (AC/DC)
Tailored arc control (DIG)
arc characteristic to be changed for
specific applications and electrodes.
Smooth running 7018 or stiffer, more
Hot Start™ adaptive control provides
positive arc starts without sticking.
AC frequency control
adds stability for
smoother welds when AC Stick welding.
Stick-Stuck detects if the electrode is
stuck to the part and turns the welding
output off to safely and easily remove
the electrode. Menu selectable.
Comes complete with
Dynasty® 280 DX AC/DC Multiprocess Welder
Coolmate™ 1.3 water cooler
Small Runner™ Cart with cylinder rack
Wireless remote foot control and receiver (301580)
Weldcraft™ W-280 torch kit and accessories (300990)
Smith® flow regulator
ArcReach® SuitCase® 12 voltage sensing wire feeder
Ground clamp with weld cable and male dinse connector
8 ft. (2.4 m.) Primary Cord
Adjustable Shoulder Strap
(2) 50 mm. Dinse-style Connectors
(2) Dinse/Tweco® Adapters (042465)
8 ft. (2.4 m.) Weld Cable with Tweco® style connectors to power feeder
Quick Reference Guide
Coolant (4 one-gallon bottles of 043810)
.035"/.045" Contact Tips
.035"/.045" Drive Rolls
15 ft. (4.5M) Bernard™ BTB MIG Gun
FREE Optrel® Panoramaxx CLT Silver auto-darkening welding helmet ($744.00 MSRP Value)
Get a FREE Optrel® Panormaxx CLT Silver auto-darkening welding helmet ($744.00 MSRP Value) with purchase of a Miller® Dynasty® 280 DX multi-process welder. Expires 9/30/22. (No substitutions allowed.)
The Optrel® Panoramaxx CLT Silver auto-darkening welding hood features Crystal shade 2.0 light state that is unmatched in the world for color and clarity and provides up to 6X the viewing area of a standard 2" X 4" auto-dark welding lens. The key to this revolutionary technology is the size and shape of the ADF, coupled with the unique Panoramaxx shell design, which allows the welding lens to be positioned closer to your face. The Panoramaxx also has advanced features like SHADETRONIC®, which automatically adjusts the shade level based on the brightness of the arc and True Color, which allows for realistic color perception in light or dark states.
All Panoramaxx welding helmets now come with the revolutionary IsoFit® headgear. It is the only welding headgear in the world that wraps the entire crown of the head with multiple touch points to provide a custom fit like never before. Independent "three dimensional" size, width and height adjustments ensure all day comfort with a secure hold.
The Panoramaxx CLT has a built-in rechargeable battery that does not need replacing. The battery is charged through arc light or when manual charging is necessary, a micro USB charging port. It comes complete with micro USB cable, helmet bag and Oprel's 2+1 warranty.
PANORAMIC FIELD OF VISION - The
Panoramaxx CLT offers a 6 times larger field
of vision than standard welding helmets – and
is still a lightweight at only 21.5 ounces.
CRYSTAL LENS TECHNOLOGY 2.0 - Shade 2.0 light state provides the brightest view of your working environment available anywhere. The natural color and clear optics supplied by CLT increases both safety and efficiency in the workplace.
SHADETRONIC® - Detection of the arc brightness and fully automated shade level adjustment from 4 to 12. Adjusts automatically to the changing light
conditions of the current welding method. A sophisticated SHADETRONIC® sensor
continuously measures the light intensity of
the welding arc and regulates the glare protection
progressively and fully automatically.
FADETRONIC - Patented Optrel FadeTronic technology gradually lightens the auto darkening filter after the welding arc is extinguished. The unpleasant afterglow is faded out – especially for high amperage applications. Eye fatigue is
significantly reduced, enhancing worker safety. FADETRONIC can be adjusted for a custom user experience.
TRUE COLOR - A specially developed UV/IR filter allows the realistic color perception typical of
Optrel®, bringing color to the welder’s
world. TRUE COLOR passes more colors of the spectrum through compared to standard "green" spectrum welding lenses.
Optrel Re-Charge - With its rechargeable
batteries is no longer
necessary. Thanks to the latest solar technology,
a rechargeable lithium-polymer battery is
recharged either by the welding light or by the
ambient light. In addition, the battery can also
be charged directly with any USB charger via
a micro-USB interface.
5-Point Detection - intelligent sensor
control with five sensors. Sophisticated software
and clever positioning of four sensors at
the corners and one sensor in the upper center
ensures the lens is switched on and
off perfectly, even in the most difficult lighting
conditions or in awkward positions.
IsoFit® headgear sets a new standard of wearing comfort. It is the only product worldwide
that can be adjusted in width, length and height – i.e. three-dimensionally – to any head shape, so that the
helmet really fits "like a glove."
FadeTronic® - gradually lightens lens when switching from dark (welding) to light state to ease eye fatigue.
Sensitivity Adjustment - allows operator to change lens switching sensitivity for varying ambient light conditions or outdoor welding in sunlight.
Grinding Mode - external grind control allows user to switch between welding mode and shade 2 grinding mode quickly and easily.
Out-Of Position Welding is possible with Optrel®'s unique shell design, which has no seams or edges where weld spatter can collect.
