Miller® Fusion 160 Welder With Electric Start 907773
The Miller® Fusion 160 with electric start is a 160 amp DC stick welder/generator that operates as either an engine driven welder or plug-in electric welder. Miller's PowerShift™ technology allows you to switch from engine power, for outdoor welding and power generation, to 120 volt or 240 volt input power for indoor use. The Fusion 160 comes with a Kohler CH440 13.4 HP single-cylinder gasoline engine with electric start and recoil (rope) backup AND Miller MVP™ (Multi-Voltage Plug) for plugging into 120 volt or 240 input power.
Weighing only 242 pounds, the Miller Fusion 160's lightweight and multiple power option means you get two welders for the price of one. When operating on engine power, the Fusion 160 is also an auxiliary power generator that produces up to 6,500 watts of electricity. It includes one 30 amp 120/240 volt twist lock receptacle and two 20 amp 120 volt duplex receptacles.Processes
DC TIG (GTAW)
Maintenance and repair
Work anywhere convenience.
PowerShift technology provides
weld capabilities using either the
Fusion 160 gasoline engine or
120/240-volt utility power. You will
have the confidence of knowing that
you can weld virtually anywhere,
outdoors and indoors, with just
one machine. The multi-voltage plug (MV™)
makes it easy to connect the welder
to either 120- or 240-volt power.
The Fusion 160 uses inverter
technology to deliver a smooth, stable
stick arc that is forgiving of variations
in arc length and travel speed, so it is
easier to produce clean welds that
meet specifications and avoid the
time and expense of rework.
Large 6.25-gallon fuel capacity
leads its class. Longer run time for
welder or generator usage.
Electric start with recoil (rope) backup provides simple, smooth engine starts. Recoil backup eliminates the worry of a dead battery.
Standard auto idle.
while not in use. Reduces fuel
consumption and noise.
Engine controls on front
switch, idle control and choke cable.
provides easy tracking
of run hours for maintenance
Easier to transport.
Fusion 160 welder/generator weighs
222 pounds. That is up to 70 pounds
less than similar machines, so moving
the Fusion 160 is easier and faster.
Less time is spent waiting, and more
work can get done.
Class-leading 6500-watt peak power
of regulated power to extend power
tool life. Accu-Rated™ peak generator power
is usable for maximum generator loads
such as plasma cutting, Millermatic® MIG welders and motor starting.
makes setting amperage levels easy.
Quick-reference parameter chart
provides convenient amperage
120/240 V twist lock and 120 V GFCI duplex receptacles
provide power for jobsite tools.
Receptacles are circuit-breaker
by protecting receptacles from debris.
air-cooled OHV engine
ensures consistent engine performance.
Comes complete with
Fusion 160 welder with electric and back up recoil (rope) start
120 V MVP™ plug
240 V MVP™ plug
FREE Miller® Classic ClearLight™ black welding hood ($127.80 MSRP Value).
Get a FREE Miller® Classic Black auto-darkening welding helmet ($127.80 MSRP Value) with purchase of a Fusion® 160 welder. Expires 9/30/22. (No substitutions allowed.)
Miller® Welding Helmet - Black Classic VS ClearLight™ Variable Shade 8-13 Auto Darkening Lens 287803
The Miller® Black Classic welding helmet features ClearLight™ four color lens technology at a surprisingly economical price. ClearLight™ offers a bright, crisp, clear view of the weld puddle with more realistic color hues in both light and dark states. The Classic Clearlight™ lens operates in weld, cut and grind modes and is DC TIG rated down to 5 amps.
The Black Classic welding hood has two arc sensors and operates in both weld and grind mode. It has a replaceable battery with solar-assist (no recharging). This welding helmet measures up to your most common DIY and light industrial welding requirements. It is lightweight, comfortable and offers unsurpassed light-state clarity and exceptional battery life.
ClearLight™ lens technology optimizes contrast
and clarity in welding and light states - reducing eye strain and operator fatigue
Variable shade 8-13
Digital Controls With Three Operating Modes -
DC TIG rated down to 5 amps
1/1/1/2 optical clarity rating
Manual On/Auto-Off circuitry
Two independent arc sensors
Features magnifying lens holder
Extra protective lens covers included
- Weld Mode™ Shades #8 - 13
- Cut Mode™ Shades #5 - 8
- Grind Mode - Light State #3
This item ships Free via standard ground shipping within contiguous U.S.
