Description
Miller® FieldPro™ Smart Feeder 300935
The Miller® FieldPro™ Smart Feeder is a portable pulsed MIG and RMD® (Regulated Metal Deposition) wire feeder that is designed to be taken into the field. It has full remote control capabilities and can be operated up to 200 feet away from the welding power source without the use of a remote control cable. The feeder communicates with the welding power source through the welding leads, eliminating the need for a remote control cable. The FieldPro Smart Feeder's RMD® technology allows even a beginner pipe welder to weld like a pro.
Suitable for use with Miller® SF (Smart Feeder) welding power sources ONLY.
Processes
MIG (GMAW)
Pulsed MIG (GMAW-P)
RMD® (Regulated Metal Deposition
Applications
Construction
High Purity Processing
Maintenance and Repair
Mechanical Contracting
Pipe Fabrication / Construction
Features
RMD and Pulsed MIG -
Smart Feeder delivers excellent RMD and Pulsed MIG welding up to 200 feet away from the power source with no control cables, twice the distance previously possible. RMD and Pulsed MIG processes also help reduce weld failures and eliminate backing gas on some stainless and chromoly applications.
Durable design reduces downtime:
Impact-resistance case and the elimination of feeder control cables provide a solid solution to last in harsh environments.
Synergic processes - RMD and Pulsed MIG welding permits procedures with one wire and one gas to eliminate process switch-over time.
Easy process changeover - Simply connect the FieldPro Smart Feeder to your leads and you are ready to go. All controls automatically shift to the FieldPro Smart Feeder.
Compatible with - Miller PipeWorx™, Big Blue® 350 PipePro™ SF and Big Blue® 800 Duo Pro SF
Comes Complete With
FieldPro™ Smart Feeder wire feeder
Inlet guide and drive rolls, .035" V / .045" VK
FREE Optrel® Panoramaxx CLT Silver auto-darkening welding helmet
Get a FREE Optrel® Panormaxx CLT Silver auto-darkening welding helmet with the purchase of this Miller® FieldPro™ 280 DX wire feeder. Expires 3/31/23. (No substitutions allowed.)
The Optrel® Panoramaxx CLT Silver auto-darkening welding hood features Crystal shade 2.0 light state that is unmatched in the world for color and clarity and provides up to 6X the viewing area of a standard 2" X 4" auto-dark welding lens. The key to this revolutionary technology is the size and shape of the ADF, coupled with the unique Panoramaxx shell design, which allows the welding lens to be positioned closer to your face. The Panoramaxx also has advanced features like SHADETRONIC®, which automatically adjusts the shade level based on the brightness of the arc and True Color, which allows for realistic color perception in light or dark states.
All Panoramaxx welding helmets now come with the revolutionary IsoFit® headgear. It is the only welding headgear in the world that wraps the entire crown of the head with multiple touch points to provide a custom fit like never before. Independent "three dimensional" size, width and height adjustments ensure all day comfort with a secure hold.
The Panoramaxx CLT has a built-in rechargeable battery that does not need replacing. The battery is charged through arc light or when manual charging is necessary, a micro USB charging port. It comes complete with micro USB cable, helmet bag and Oprel's 2+1 warranty.
Features
PANORAMIC FIELD OF VISION - The
Panoramaxx CLT offers a 6 times larger field
of vision than standard welding helmets – and
is still a lightweight at only 21.5 ounces.
CRYSTAL LENS TECHNOLOGY 2.0 - Shade 2.0 light state provides the brightest view of your working environment available anywhere. The natural color and clear optics supplied by CLT increases both safety and efficiency in the workplace.
SHADETRONIC® - Detection of the arc brightness and fully automated shade level adjustment from 4 to 12. Adjusts automatically to the changing light
conditions of the current welding method. A sophisticated SHADETRONIC® sensor
continuously measures the light intensity of
the welding arc and regulates the glare protection
progressively and fully automatically.
FADETRONIC - Patented Optrel FadeTronic technology gradually lightens the auto darkening filter after the welding arc is extinguished. The unpleasant afterglow is faded out – especially for high amperage applications. Eye fatigue is
significantly reduced, enhancing worker safety. FADETRONIC can be adjusted for a custom user experience.
TRUE COLOR - A specially developed UV/IR filter allows the realistic color perception typical of
Optrel®, bringing color to the welder’s
world. TRUE COLOR passes more colors of the spectrum through compared to standard "green" spectrum welding lenses.
Optrel Re-Charge - With its rechargeable
power-pack, changing
batteries is no longer
necessary. Thanks to the latest solar technology,
a rechargeable lithium-polymer battery is
recharged either by the welding light or by the
ambient light. In addition, the battery can also
be charged directly with any USB charger via
a micro-USB interface.
5-Point Detection - intelligent sensor
control with five sensors. Sophisticated software
and clever positioning of four sensors at
the corners and one sensor in the upper center
ensures the lens is switched on and
off perfectly, even in the most difficult lighting
conditions or in awkward positions.
IsoFit® headgear sets a new standard of wearing comfort. It is the only product worldwide
that can be adjusted in width, length and height – i.e. three-dimensionally – to any head shape, so that the
helmet really fits "like a glove."
FadeTronic® - gradually lightens lens when switching from dark (welding) to light state to ease eye fatigue.
Sensitivity Adjustment - allows operator to change lens switching sensitivity for varying ambient light conditions or outdoor welding in sunlight.
Grinding Mode - external grind control allows user to switch between welding mode and shade 2 grinding mode quickly and easily.
Delay Function
Out-Of Position Welding is possible with Optrel®'s unique shell design, which has no seams or edges where weld spatter can collect.
Specs
Comes complete with
Micro USB charging cable
Helmet bag
1 extra outside cover plate
2+1 warranty
This item ships Free via standard ground shipping within contiguous U.S.
