ESAB Renegade ES 300i Stick Welder 0445100881

ESAB® Renegade™ ES 300i Stick Welder 0445100881

The ESAB® Renegade™ ES 300i is a 300 amp portable DC Stick/TIG welder that weighs just 33 pounds and runs on single or 3-phase input power. The Renegade ES 300i senses 208-460 input voltage, 1-Phase or 3-Phase power and automatically adjusts to the optimal welding output. Its 300 amps of stick welding output is ideal for electrodes up to 3/16 inch in diameter. Adjustable Arc Force and Hot Start controls allow you to customize your arc for the perfect weld every time, even with E6010.

The Renegde ES 300i is also capable of DC TIG welding up to 300 amps on mild steel and stainless steel, with OPTIONAL TIG torch. It comes complete with digital meter, ten foot input power cable, ten foot lead cable with electrode holder, ten foot ground cable with clamp and ESAB's 3-year warranty. The Renegade is IP23 designed to be used with confidence indoors or outdoors.

Process

• Stick (SMAW)
• DC TIG (GTAW)

  Applications
  Ship and Offshore Yards
  Civil Construction
  Pipe Construction
  Repair and Maintenance
  Heavy Fabrication
  Industrial and General Fabrication
  Mining
  Steel Erectors



  Features
• Multi-voltage, multi-phase input power
  Automatically adjusts to operate on 208-460 volt, single-phase or 3-phase input power.
• Highest power to weight ratio in its class
  Weighing in at 33 lbs. (15 kg) and producing 300A at 40% duty cycle (Stick). Combined with its rugged case, Renegade is ideal for the most extreme environments in the industry.
• Small, lightweight system
  Can virtually go anywhere on the jobsite. Its three handle design makes it easy for transportation and maneuvering through manholes and other hard to reach areas.
• Excellent performance on 6010 (cellulosic) electrodes
  And additional functionally to tailor Arc Force for a softer or crisper arc. With an excellent TIG operational range from 5 to 300 A, you’ll have the confidence to tackle a broad range of material thicknesses.
• Intuitive interface
  The welder’s digital readout display, along with large buttons with excellent feedback and controls, make it easy to set parameters and read them from a distance.
• Cable management
  An integrated latch system helps control cables so they can be secured to the machine, making it easy to pack up and go
• Robust Design
  IP23 designed for fabrication shop or site application

NOTE: This is a DC welder ONLY. It CANNOT TIG weld aluminum.



ESAB's industry-leading service and support means that if you do need help with your welder, you will be protected. 100% SATISFACTION GUARANTEE means that if there's anything you're not completely satisfied with in your first 100 days with your new Rogue, ESAB will make it right, even if it means giving you your money back. It's all part of ESAB's Iron Clad Pledge to its customers.

Comes Complete With:

• Renegade™ ES 300i DC Stick/TIG welder
• 10 ft. input power cable
• (2) male 50mm dinse (OKC) connector
• Digital meter
• Shoulder strap
