Miller® Fusion 185 Welder With Electric Start 907781
The Miller® Fusion 185 with electric start is a 185 amp DC stick welder/generator that operates as either an engine driven welder or plug-in electric welder. Miller's PowerShift™ technology allows you to switch from engine power, for outdoor welding and power generation, to 120 volt or 240 volt input power for indoor use. The Fusion 185 comes with a Kohler CH440 13.4 HP single-cylinder gasoline engine with electric start and recoil (rope) backup AND Miller MVP™ (Multi-Voltage Plug) for plugging into 120 volt or 240 input power.
Weighing only 242 pounds, the Miller Fusion 185's lightweight and multiple power option means you get two welders for the price of one. When operating on engine power, the Fusion 185 is also an auxiliary power generator that produces up to 6,500 watts of electricity. It includes one 30 amp 120/240 volt twist lock receptacle and two 20 amp 120 volt duplex receptacles.
Processes
Stick (SMAW)
DC TIG (GTAW)
AC Generator
Applications:
Construction
Maintenance and repair
Farm/ranch applications
Service trucks
Stand-alone generator
Features:
Work anywhere convenience. PowerShift technology provides weld capabilities using either the Fusion 185's Kohler® gasoline engine or 120/240-volt utility power. You will have the confidence of knowing that you can weld virtually anywhere, outdoors and indoors, with just one machine. The multi-voltage plug (MV™) makes it easy to connect the welder to either 120- or 240-volt power.
Less rework. The Fusion 185 uses inverter technology to deliver a smooth, stable stick arc that is forgiving of variations in arc length and travel speed, so it is easier to produce clean welds that meet specifications and avoid the time and expense of rework.
Large 6.25-gallon fuel capacity leads its class. Longer run time for welder or generator usage.
Electric start with recoil (rope) backup provides simple, smooth engine starts. Recoil backup eliminates the worry of a dead battery.
Standard auto idle. Idles engine while not in use. Reduces fuel consumption and noise.
Engine controls on front for engine switch, idle control and choke cable.
Hour meter provides easy tracking of run hours for maintenance intervals.
Easier to transport. Fusion 185 welder/generator weighs 242 pounds. That is up to 50 pounds less than similar machines, so moving the Fusion 185 is easier and faster. Less time is spent waiting, and more work can get done.
Class-leading 6500-watt peak power of regulated power to extend power tool life. Accu-Rated™ peak generator power is usable for maximum generator loads such as plasma cutting, Millermatic® MIG welders and motor starting.
Single-range amperage control makes setting amperage levels easy.
Quick-reference parameter chart provides convenient amperage setting guidance.
120/240 V twist lock and 120 V GFCI duplex receptacles provide power for jobsite tools. Receptacles are circuit-breaker protected. Receptacle covers improve reliability by protecting receptacles from debris.
Reliable air-cooled OHV engine ensures consistent engine performance.
Comes complete with
Fusion 185 welder with electric and back up recoil (rope) start
120 V MVP™ plug
240 V MVP™ plug
FREE Miller® Classic ClearLight™ black welding hood
Get a FREE Miller® Classic Black auto-darkening welding helmet with the purchase of this Fusion® 185 welder. While supplies last. (No substitutions allowed.)Miller® Welding Helmet - Black Classic VS ClearLight™ Variable Shade 8-13 Auto Darkening Lens 287803
The Miller® Black Classic welding helmet features ClearLight™ four color lens technology at a surprisingly economical price. ClearLight™ offers a bright, crisp, clear view of the weld puddle with more realistic color hues in both light and dark states. The Classic Clearlight™ lens operates in weld, cut and grind modes and is DC TIG rated down to 5 amps.
The Black Classic welding hood has two arc sensors and operates in both weld and grind mode. It has a replaceable battery with solar-assist (no recharging). This welding helmet measures up to your most common DIY and light industrial welding requirements. It is lightweight, comfortable and offers unsurpassed light-state clarity and exceptional battery life.
Features
ClearLight™ lens technology optimizes contrast and clarity in welding and light states - reducing eye strain and operator fatigue
Variable shade 8-13
Digital Controls With Three Operating Modes -
- Weld Mode™ Shades #8 - 13
- Cut Mode™ Shades #5 - 8
- Grind Mode - Light State #3
DC TIG rated down to 5 amps
1/1/1/2 optical clarity rating
Manual On/Auto-Off circuitry
Two independent arc sensors
Features magnifying lens holder
Extra protective lens covers included
PLUS get a $400 cash rebate from Miller® with the purchase of this Miller® Fusion 185 welder. Rebate form must be submitted online HERE within 30 days of original purchase. Offer expires 9/30/23.
Earn additional rebates when you purchase additional Miller® branded accessories or Hobart® filler metals.
