Smith CO2 Flowmeter Regulator - 2 Stage, High Flow 35-30-320

Code: 35-30-320

Skip to product information
1 of 1

Cyberweld Price $375.35
Cyberweld Price $375.35
Mfg Industrial Price: $750.67
(You Save $375.32)

Gas:CO2

-
+
WARNING: Cancer and Reproductive Harm - P65Warnings.ca.gov
FAST & FREE SHIPPING On All Orders Over $50


Smith CO2 Flowmeter Regulator - 2 Stage, High Flow 35-30-320

The Smith® 35-30-320 is a high-flow, two stage CO2 (Carbon Dioxide) flowmeter regulator that provides consistent outlet pressure while avoiding freeze ups. The heavy duty design is constructed with two 15 micron nickel plated bronze (Sure-Seat™) filters which encapsulate the high pressure seats. These filters protect the seating surfaces from any external debris or ice that may enter the seating area during operation.

This design provides a higher quality regulator for extended service life and improved performance. It is also constructed with a coiled copper tube which the CO2 gas flows through. This helps warm the gas with ambient room temperature reducing freeze-up conditions thereby allowing greater CO2 flow capabilities and it requires no electricity. The two stage design virtually eliminates decay/rise which provides highly accurate flow rates from a full to an empty cylinder. Also, the two stage design combined with the self-centering ball flow tube, dramatically reduces gas consumption for exceptional cost savings. The 35-30-580 has a delivery pressure of 30 PSIG and is designed for high flow CO2 applications, however, it may also be used for Argon or Helium gases. A cylinder connection adapter or a different inlet connection will be needed for use with other compatible gases.



Applications
Pressure & Flow Regulation, Two Stage
Inert & Carbon Dioxide Pressurized Cylinders
MIG & TIG welding applications
High flow CO2 applications

Features
  • The Lexan® flowtube is surrounded by our exclusive hard hat enclosure protecting it from external damage.
  • The 35-30-320 is UL Listed, covered by a 3 year limited warranty and made in the USA.
  • The high performance 35-30-320 delivers exceptionally precise gas control as well as unmatched gas conservation.
